PCBA Separator, SMTfly-1A460 Features:

1.Firm machine structure be designed to prevent electronic circuit, solder point, and solder cutting area of PCB from damage by unsuitable force.

2.Effectively reduce stress and prevent solder point chap from PCB cutting.
3.PCB cutting speed can be adjusted by the rotary knob.
4.PCB cutting stroke can be set free and setting value can be showed in LCD.
5.Clearance between circular and linear blades are adjusted to fit different V groove depth and compensates for blade wear out
6.Optional PCB conveyor belt to remove finished PCB cut .

7.Have safety sensor to protect hands

Motorized PCBA Separator, SMTfly-1A460 Specification:

Model	SMTfly-1A460
Max. PCB cutting length	460mm
PCB cutting thickness	0.6-3.5 mm
PCB cutting speed	100,200,300,500 mm/sec
Blade motion	upper circular blade moving automatically
Blade motive power operating mode	motor-driven
Power supply	110/220v
PCB cutting machine size	770510450mm
PCB cutting machine weight	55kg
